| Design |
|---|
| Colour name |
Dark Tech Blue |
| Product type |
Notebook |
| Form factor |
Clamshell |
| Product colour |
Black |
| Display |
|---|
| HD type |
Full HD |
| Display surface |
Matt |
| Panel type |
IPS |
| LED backlight |
Yes |
| Touchscreen |
No |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
35.6 cm (14") |
| Native aspect ratio |
16:9 |
| Processor |
|---|
| Processor generation |
12th gen Intel Core i5 |
| Configurable TDP-down |
20 W |
| Processor cache type |
Smart Cache |
| Processor cache |
12 MB |
| Processor frequency |
3.3 GHz |
| Processor model |
i5-1240P |
| Processor boost frequency |
4.4 GHz |
| Processor cores |
12 |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core i5 |
| Memory |
|---|
| Internal memory |
8 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory clock speed |
3200 MHz |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
32 GB |
| Storage |
|---|
| SSD form factor |
M.2 |
| Storage media |
SSD |
| Optical drive type |
No |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
NVMe, PCI Express |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Total storage capacity |
256 GB |
| Total SSDs capacity |
256 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel Iris Xe Graphics |
| Discrete graphics card model |
Not available |
| Audio |
|---|
| Number of microphones |
2 |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| WLAN controller manufacturer |
Intel |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| Charging port type |
USB Type-C |
| Thunderbolt 4 ports quantity |
2 |
| Intel Thunderbolt 4 |
Yes |
| Keyboard |
|---|
| Pointing device |
Touchpad |
| Numeric keypad |
No |
| Keyboard backlit |
Yes |
| Software |
|---|
| Operating system architecture |
64-bit |
| Trial software |
Microsoft Office 365 |
| Operating system installed |
Windows 11 Pro |
| Technical details |
|---|
| Form factor |
Clamshell |
| Product colour |
Black |
| Compatible products |
�This system is preinstalled with Windows 10 Pro software and also comes with a license and media for Windows 11 Pro. Note that media is not included if it can be downloaded over the network. You may only use one version of the Windows software at a time. Switching between versions may require you to uninstall one version and install the other version. |
| Number of pins |
3 |
| Processor special features |
|---|
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Execute Disable Bit |
Yes |
| Embedded options available |
No |
| CPU configuration (max) |
1 |
| Intel Virtualization Technology (VT-x) |
Yes |
| Battery |
|---|
| Battery technology |
Lithium Polymer (LiPo) |
| Number of battery cells |
4 |
| Battery life (max) |
9.17 h |
| Battery capacity |
53 Wh |
| Power |
|---|
| AC adapter power |
65 W |
| AC adapter input voltage |
100 - 240 V |
| AC adapter output voltage |
5, 9, 15, 20 V |
| USB charging voltage |
5,9,15,20 V |
| Security |
|---|
| Password protection |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Password protection type |
SSD, Supervisor, User |
| Fingerprint reader |
Yes |
| Face recognition |
Yes |
| Cable lock slot |
Yes |
| Windows Hello |
Yes |
| Smart card reader |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Certificates |
|---|
| Wi-Fi certified |
Yes |
| Certification |
The manufacturer declares that this product complies with the following directives and regulations for the CE-marking. Responsible for CE marking is Dynabook Europe GmbH, Stresemannallee 4b, 41460 Neuss, Germany. |
| Weight & dimensions |
|---|
| Width |
323.6 mm |
| Depth |
220.6 mm |
| Height |
17.9 mm |
| Weight |
1.46 kg |
| Other features |
|---|
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Compatible products |
�This system is preinstalled with Windows 10 Pro software and also comes with a license and media for Windows 11 Pro. Note that media is not included if it can be downloaded over the network. You may only use one version of the Windows software at a time. Switching between versions may require you to uninstall one version and install the other version. |
| On-board graphics card |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Number of pins |
3 |
