Gigabyte AORUS GeForce RTX 4060 Ti ELITE 8G NVIDIA 8 GB GDDR6 Graphics Card
Key Features
- Graphics Processor: GeForce RTX 4060 Ti
- Interface Type: PCI Express 4.0
- Memory Type: GDDR6
- Memory Bus: 128
- Maximum Resolution: 7680 x 4320
- Ports: 2 DisplayPorts
Overview
THE EVOLVING POWER OF WINDFORCE The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 4 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation. UNIQUE BLADE FAN The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface. GRAPHENE NANO LUBRICANT Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter. HEAT PIPES DIRECT TOUCH The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a metal plate contact to ensure proper cooling. ALTERNATE SPINNING Each fan rotates in different direction to the adjacent one. This special mechanism reduces turbulence and increases air pressure by minimizing the offset occurred between airflows. 3D ACTIVE FAN The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. SCREEN COOLING To create more space for airflow to pass through, the heatsink extends over the PCB and therefore increase the ventilation. This Screen Cooling design provides better heat dissipation. RGB FUSION The legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER. DUAL BIOS The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience. PROTECTION METAL BACK PLATE The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection. POWER INDICATOR When experiencing any power supply abnormality, the indicator will alert gamers by flashing light. PCB COATING Dust resistant - shields from dust, insects, dropped screws, drill shavings, and abrasion. Moisture resistant - prevents unwanted conduction paths and board damage. Corrosion resistant - protects from salt spray, humidity, and corrosion. EXTREME OVERCLOCKING The graphics card features excellent power phase design to allow the MOSFETs to operate at lower temperatures and provide a more stable voltage output. Load balancing of each MOSFET can effectively improve the overclocking performance and extend the life of the card. FRIENDLY PCB DESIGN Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build. ULTRA DURABLE Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life. 4-YEAR WARRANTY We want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase. GIGABYTE CONTROL CENTER GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time
| Processor |
|---|
| Graphics processor family |
NVIDIA |
| Processor boost clock speed |
2655 MHz |
| Parallel processing technology support |
Not supported |
| Maximum displays per videocard |
4 |
| CUDA cores |
4352 |
| CUDA |
Yes |
| Maximum resolution |
7680 x 4320 pixels |
| Graphics processor |
GeForce RTX 4060 Ti |
| Memory |
|---|
| Discrete graphics card memory |
8 GB |
| Memory clock speed |
1800 MHz |
| Memory bus |
128 bit |
| Graphics card memory type |
GDDR6 |
| Ports & interfaces |
|---|
| HDMI version |
2.1a |
| HDMI ports quantity |
2 |
| DisplayPort version |
1.4a |
| DisplayPorts quantity |
2 |
| Interface type |
PCI Express 4.0 |
| Video |
|---|
| DirectX version |
12.0 |
| OpenGL version |
4.6 |
| HDMI version |
2.1a |
| HDCP |
Yes |
| Dual Link DVI |
No |
| CUDA cores |
4352 |
| Performance |
|---|
| DirectX version |
12.0 |
| OpenGL version |
4.6 |
| HDCP |
Yes |
| Dual Link DVI |
No |
| TV tuner integrated |
No |
| Design |
|---|
| Number of fans |
3 fan(s) |
| Cooling type |
Active |
| Form factor |
Full-Height/Full-Length (FH/FL) |
| Product colour |
Black |
| Power |
|---|
| Supplementary power connectors |
1x 8-pin |
| Minimum system power supply |
500 W |
| Technical details |
|---|
| Cooling type |
Active |
| Form factor |
Full-Height/Full-Length (FH/FL) |
| Product colour |
Black |
| TV tuner integrated |
No |
| System requirements |
|---|
| Minimum system power supply |
500 W |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| Weight & dimensions |
|---|
| Width |
128 mm |
| Height |
56 mm |
| Depth |
301 mm |
| Packaging data |
|---|
| Package type |
Box |
