Great performance and impressive lighting
The Light Wings LX 140mm PWM White Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
SHOW WHAT YOU GOT
A fan made for show cases
Light Wings LX 140mm PWM White undeniably upgrades all kind of PC cases with its spectacular lighting. Especially show cases with an emphasis on ARGB illumination benefit from this fan. Add a bunch of them to your showcase and let friends and family gaze in awe.
IMPRESSIVE LIGHTING
Lots of illumination possibilities
16 LEDs are located inside the hub of the impeller of the Light Wings LX 140mm PWM White and shine outwards onto the frosted fan blades. This creates an unmistakable look and enables you to express your creativity.
YOUR CASE FAN OF CHOICE
Optimized fan blades and frame
Light Wings LX 140mm PWM White features a fan frame outlet that minimizes air leaks. In addition, the fan blades are optimized for maximum airflow, making this fan the best-in-class choice for virtually any case configuration.
DAISY CHAIN IT!
One connector for all your Light Wings LX fans
The ARGB connection cable comes with an input and an output connector. The input can be used to connect the fan to your motherboard or to an ARGB controller, but also to daisy-chain it with the output connector of other Light Wings LX fans.
RIFLE BEARING TECHNOLOGY
Makes Light Wings LX a long-lasting companion
Light Wings LX 140mm PWM White is built to last. With the proven rifle bearing technology, on average, this fan offers a lifespan of 60,000 hours.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1200 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 22.9 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 56 cfm |
| Maximum air pressure | 0.9 mmH2O |
| Airflow | 95 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 7 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | White |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 7 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 22.9 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 56 cfm |
| Maximum air pressure | 0.9 mmH2O |
| Airflow | 95 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.3 A |
| Fan power consumption | 3.6 W |
| Fan current | 0.09 A |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 140 x 140 x 25 mm |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Fan weight | 169 g |
| Package weight | 580 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Package weight | 580 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 30.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 36 cm |
| Shipping (inner) case gross weight | 12.4 kg |
| Products per shipping (inner) case | 20 pc(s) |
Great performance and impressive lighting
The Light Wings LX 140mm PWM high-speed Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1800 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 9 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 9 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.45 A |
| Fan power consumption | 5.4 W |
| Fan voltage | 12 V |
| Fan current | 0.18 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 140 x 140 x 25 mm |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Fan weight | 169 g |
| Package weight | 590 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Package weight | 590 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 30.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 36 cm |
| Shipping (inner) case gross weight | 12.6 kg |
| Products per shipping (inner) case | 20 pc(s) |
Great performance and impressive lighting
The Light Wings LX 120mm PWM boasts optimized fan blades and an illuminated impeller for great performance and lighting.
SHOW WHAT YOU GOT
A fan made for show cases
Light Wings LX 120mm PWM undeniably upgrades all kind of PC cases with its spectacular lighting. Especially show cases with an emphasis on ARGB illumination benefit from this fan. Add a bunch of them to your showcase and let friends and family gaze in awe.
IMPRESSIVE LIGHTING
Lots of illumination possibilities
16 LEDs are located inside the hub of the impeller of the Light Wings LX 120mm PWM and shine outwards onto the frosted fan blades. This creates an unmistakable look and enables you to express your creativity.
YOUR CASE FAN OF CHOICE
Optimized fan blades and frame
Light Wings LX 120mm PWM features a fan frame outlet that minimizes air leaks. In addition, the fan blades are optimized for maximum airflow, making this fan the best-in-class choice for virtually any case configuration.
DAISY CHAIN IT!
One connector for all your Light Wings LX fans
The ARGB connection cable comes with an input and an output connector. The input can be used to connect the fan to your motherboard or to an ARGB controller, but also to daisy-chain it with the output connector of other Light Wings LX fans.
RIFLE BEARING TECHNOLOGY
Makes Light Wings LX a long-lasting companion
Light Wings LX 120mm PWM is built to last. With the proven rifle bearing technology, on average, this fan offers a lifespan of 60,000 hours.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1600 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 1 pc(s) |
| Number of fan blades | 7 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 1 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 7 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 1 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.32 A |
| Fan power consumption | 3.8 W |
| Fan current | 0.1 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 27 mm |
| Fan weight | 133 g |
| Package weight | 170 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 27 mm |
| Package weight | 170 g |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 4 |
| Logistics data | |
| Shipping (inner) case width | 31.9 cm |
| Shipping (inner) case length | 43.3 cm |
| Shipping (inner) case height | 29 cm |
| Shipping (inner) case gross weight | 10.8 kg |
| Products per shipping (inner) case | 60 pc(s) |
Great performance and impressive lighting
The Light Wings LX 120mm PWM Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1600 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 7 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 7 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.32 A |
| Fan power consumption | 3.8 W |
| Fan voltage | 12 V |
| Fan current | 0.1 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Fan weight | 133 g |
| Package weight | 470 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Package weight | 470 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 26.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 32 cm |
| Shipping (inner) case gross weight | 10.2 kg |
| Products per shipping (inner) case | 20 pc(s) |
Experience Cooling in High Definition
Cooler Master's latest flagship performance cooler, the MasterLiquid 360 Ion, is our first liquid cooler to feature an LCD display. The MasterLiquid 360 Ion gives you total display customization with top-tier cooling specs.
Gen X Dual Chamber Design
Our signature dual chamber pump has been refined for enhanced cooling synergy. Our impeller uses a single-piece design with improved structural strength and stability. The graphite ceramic shaft is highly sturdy and temperature resistant.
2.1-inch LCD Screen
The Ion's pump features a 2.1-inch LCD screen, fully customizable with our MasterCtrl software. Meanwhile, Our ARGB halo lighting has been designed with the Cooler Master's signature aesthetic in mind.
Highly Customizable and Compatible
Built-in features such as controllable ARGB lighting and automatic PWM adjustment are compatible with all major motherboards and allow for in-depth customization.
Mobius 120P ARGB fans
Pre-installed with three Mobius 120P ARGB fans for unmatched cooling performance. The interconnecting fan blades have been designed with a balanced P/Q curve suitable for both air and liquid cooling.
IN-HOUSE DESIGNED RADIATOR
A low-profile radiator with superior fin density and high-performance fans rapidly dissipates heat.
TUBE CLIPS INCLUDED
Included tube clips made to fit the AIO tube not only improve and strengthen your cooling setup, but they can also help with cable management.
ECO-FRIENDLY PACKAGING WITH ENHANCED PROTECTION
Building off the modular packaging of our Atmos cooler, the Ion's packaging features 30% reduced volume and an optimized internal cushioning structure.
USING EPDM + IIR COMPOSITE MATERIALS
Our AIO cooler uses ERPDM and IIR composite materials to lower the evapotranspiration rate and water flow resistance, at the same time, improve the air tightness and bendability
| Performance | |
|---|---|
| Suitable location | Processor |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Loop Dynamic Bearing (LDB) |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 75.2 cfm |
| Maximum air pressure | 3.63 mmH2O |
| Airflow | 107.1 m³/h |
| Number of fans | 3 fan(s) |
| Quantity per pack | 1 pc(s) |
| Pump connector | 4-pin |
| Fan noise level (max) | 30 dB |
| Pump noise level | 20 dB |
| Fan speed (min) | 0 RPM |
| Fan speed (max) | 2400 RPM |
| Pump's mean time to failure (MTTF) | 210000 h |
| Fan's mean time to failure (MTTF) | 200000 h |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Technical details | |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 75.2 cfm |
| Maximum air pressure | 3.63 mmH2O |
| Airflow | 107.1 m³/h |
| Number of fans | 3 fan(s) |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Pump connector | 4-pin |
| Power | |
| Safety current | 0.35 Ah |
| Rated voltage | 12 V |
| Pump power consumption | 6.75 W |
| Pump voltage | 12 V |
| Fan voltage | 12 V |
| Fan current | 0.18 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 410 mm |
| Package width | 211 mm |
| Package height | 136 mm |
| Package weight | 3.12 kg |
| Weight | 2 kg |
| Radiator width | 12 cm |
| Radiator depth | 39.4 cm |
| Radiator height | 2.72 cm |
| Pump width | 8.36 cm |
| Pump depth | 8.83 cm |
| Pump height | 6.57 cm |
| Packaging data | |
| Package depth | 410 mm |
| Package width | 211 mm |
| Package height | 136 mm |
| Package weight | 3.12 kg |
| Indication | |
| Illumination colour | Multi |
| Other features | |
| Safety current | 0.35 Ah |
| Country of origin | China |
| Pump connector | 4-pin |
| Logistics data | |
| Products per master (outer) case | 4 pc(s) |
| Master (outer) case width | 430 mm |
| Master (outer) case length | 430 mm |
| Master (outer) case height | 300 mm |
Cool Efficiency Redefined
Cooler Master’s masterclass HYPER 212 series makes a triumphant return with the HYPER 212 PRO, a new take on a classic design featuring our in-house design heat pipes.
Higher TDP
The newly designed CPU cooler introduces an all-new heat pipe, increasing the TDP to 230W. This means it can handle the cooling of higher power CPUs effectively
100% RAM Clearance
A novel asymmetrical heat pipe layout and design provides more RAM clearance than ever before.
Optimized Tower Cooler Design
The optimized design ensures better airflow and heat dissipation, which results in improved cooling efficiency and overall system performance.
Superconductive Composite Heat Pipes
By using various evaporator and condensor wick structures, our SCHPs greaty enhance performace for improved heat dissipation
All-new Top Cover Design
A sleek and modern top cover enhances the overall look of your build, giving it a stylish and professional appearance.
SickleFlow Edge 120 Fans
A SickleFlow Edge fan combines exceptional heat dissipation performance with a visually striking design.
Easy fan mount
Simplifies the installation process, allowing users to set up the cooler quickly and efficiently.
| Performance | |
|---|---|
| Suitable location | Processor |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (min) | 690 RPM |
| Rotational speed (max) | 2500 RPM |
| Fins material | Aluminium |
| Bearing type | Loop Dynamic Bearing (LDB) |
| Noise level (high speed) | 32.8 dB |
| Number of heat pipes | 4 |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 70.7 cfm |
| Maximum air pressure | 3.61 mmH2O |
| Airflow | 120 m³/h |
| Number of fans | 1 fan(s) |
| Fan's mean time to failure (MTTF) | 160000 h |
| Design | |
| Fan connector | 4-pin |
| Fins material | Aluminium |
| Number of heat pipes | 4 |
| Number of fans | 1 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Illumination LED | Yes |
| Technical details | |
| Noise level (high speed) | 32.8 dB |
| Number of heat pipes | 4 |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 70.7 cfm |
| Maximum air pressure | 3.61 mmH2O |
| Airflow | 120 m³/h |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Safety current | 0.3 Ah |
| Rated voltage | 12 V |
| Rated current | 0.2 A |
| Fan power consumption | 2.4 W |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 148 mm |
| Package width | 118 mm |
| Package height | 182 mm |
| Width | 74 mm |
| Package weight | 890 g |
| Depth | 125 mm |
| Height | 152 mm |
| Weight | 700 g |
| Packaging data | |
| Package depth | 148 mm |
| Package width | 118 mm |
| Package height | 182 mm |
| Package weight | 890 g |
| Indication | |
| Illumination colour | Multi |
| Other features | |
| Safety current | 0.3 Ah |
| Logistics data | |
| Products per master (outer) case | 8 pc(s) |
| Master (outer) case width | 310 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case height | 210 mm |
DIRECT-TO-MOTHERBOARD CONNECTION
Skip the fan hubs and excessive cables – daisy-chain your RS Series fans in sequence and control them all through just a single 4-pin PWM connector on your motherboard.
AIRFLOW AND STATIC PRESSURE
A better fan relies on several key features, each improving how it handles air pressure and airflow as a radiator or case fan. RS fans were engineered to excel at both.
BLADE SHAPE
Optimized angle of attack, airfoil shape, and edge curvature ensure maximum airflow efficiency.
FAN HOUSING
The fan housing was designed to support the largest possible blade radius within its size limit.
CORSAIR AIRGUIDE
Stator vanes are angled to focus the exhaust airflow cone and improve the coverage of radiator fins and heat dissipation.
EVERY SOURCE OF NOISE ADDRESSED
MAGNETIC DOME BEARING
This improved bearing minimizes friction and mechanical noise, achieving a balance between high airflow performance and low acoustic footprint. On top of that, the reduced friction means greater longevity for your fan.
STRENGTH IN NUMBERS
PROVEN COOLING PERFORMANCE
RS fans have undergone months of extensive testing to guarantee exceptional performance at the full range of PWM fan speeds set with their direct-to-motherboard connection.
Read more about how radiator fan performance is actually measured, what the specifications mean in practice and what separates good fans from great fans.
ZERO RPM MODE
PWM control lets you precisely set fan speeds so your fans only spin as fast as they need to, resulting in less fan noise overall, while support for Zero RPM means they can stop spinning completely at low loads to eliminate fan noise.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (min) | 330 RPM |
| Rotational speed (max) | 1700 RPM |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Minimum airflow (imperial) | 14.6 cfm |
| Maximum airflow | 95.5 cfm |
| Minimum air pressure | 0.11 mmH2O |
| Maximum air pressure | 3.46 mmH2O |
| Number of fans | 2 fan(s) |
| Quantity per pack | 2 pc(s) |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 2 fan(s) |
| Product colour | White |
| Technical details | |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Minimum airflow (imperial) | 14.6 cfm |
| Maximum airflow | 95.5 cfm |
| Minimum air pressure | 0.11 mmH2O |
| Maximum air pressure | 3.46 mmH2O |
| Number of fans | 2 fan(s) |
| Fan connector | 4-pin |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Fan current | 0.45 A |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 140 x 140 x 25 mm |
| Fan weight | 624 g |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 8 |
| Package type | Box |
IT'S COOLER AT THE TOP
POWERFUL AND EFFICIENT ALL-IN-ONE CPU COOLING
For cutting-edge systems that need to get the most out their CPUs, the TITAN RX RGB towers above the competition. Thousands of hours of in-house engineering culminate in a CPU cooler that combines unparalleled performance, impressively quiet acoustics, and simplified iCUE LINK connections.
PERFORMANCE WHERE IT MATTERS
PEAK COOLING POWER
Push airflow through radiators like never before at low, medium, and high speeds. RX Series fans deliver high airflow and static pressure, while keeping noise as low as possible.
FLOWDRIVE COOLING ENGINE
Designed in-house by CORSAIR's expert engineers, the pump is powered by a three-phase motor with a higher flow rate and even lower noise levels than its predecessors. Add to that a precision-engineered cold plate surface profile that maximizes contact with your CPU’s IHS, and you have a recipe for consistently lower temperatures.
MAKE IT PERSONAL
CAPSWAP MODULAR DESIGN
It's never been easier to change the look or functionality of your AIO. Switch the default pump cap with any CapSwap module (sold separately) in seconds, completely tool-free, and it's almost like a brand-new cooler.
EASY INSTALLATION FOR INTEL AND AMD CPUs
Includes mounting brackets and backplates for fast installation on a wide range of socket types, including modern Intel® LGA 1851/1700 and AMD® AM5/AM4.
KEEPING UP APPEARANCES
YOUR COOLER HAS NEVER LOOKED COOLER
PUMP CAP
The TITAN RX RGB’s unique pump cap design shows off the lighting from 20 individually addressable RGB LEDs around the pump.
DETACHABLE SIDE PLATES
Each RX RGB fan comes with a pair of decorative side plates, providing a choice between a translucent window or a CORSAIR wordmark.
FAN LIGHTING
Eight individually addressable RGB LEDs per fan display mesmerizing effects, easily synchronized with your pump lighting.
EXTREME PERFORMANCE THERMAL PASTE
For top-notch performance, every detail in the heat transfer and dissipation chain matters.
All TITAN RX RGB CPU blocks include pre-applied CORSAIR XTM70 Extreme Performance Thermal Paste for maximum heat transfer from your high-end processor to the cooler cold plate.
GET STARTED FAST WITH iCUE
See how easy it is to install your new CORSAIR components and set things up in iCUE software.
| Performance | |
|---|---|
| Suitable location | Processor |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 2100 RPM |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Minimum air pressure | 0.12 mmH2O |
| Maximum air pressure | 4.33 mmH2O |
| Number of fans | 2 fan(s) |
| Quantity per pack | 1 pc(s) |
| Design | |
| Number of fans | 2 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Technical details | |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Minimum air pressure | 0.12 mmH2O |
| Maximum air pressure | 4.33 mmH2O |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Warranty period | 6 year(s) |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Width | 334 mm |
| Depth | 456 mm |
| Height | 444 mm |
| Weight | 1.55 kg |
| Radiator width | 27.7 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Indication | |
| Illumination colour | Multi |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Package type | Box |
| Mounting kit | Yes |
| CPU bracket(s) | Yes |
NAUTILUS 360 RS ARGB Liquid CPU Cooler - White
The CORSAIR NAUTILUS RS ARGB Liquid CPU Cooler delivers efficient, low-noise cooling with straightforward connectivity – no controller required, just plugs directly into your motherboard.
COOL, QUIET, POWERFUL SIMPLE, FOCUSED PERFORMANCE
Renowned CORSAIR engineering delivers high-performance, low-noise cooling, enabling your CPU to reach its full potential.
MADE TO FIT MAXIMUM CONTACT
The slightly convex design ensures optimal contact with your CPU’s integrated heat spreader, with thermal paste applied in an optimized pattern to speed up installation.
FOCUSED AIRFLOW
HIGH AIRFLOWAND STATICPRESSURE
RS120 ARGB Fans deliver powerful airflow with high static pressure to push air through the radiator. CORSAIR AirGuide technology and Magnetic Dome bearings ensure excellent cooling performance while keeping noise to a minimum.
STAY CONNECTED
DAISY-CHAINEDCONNECTIONS
Simplify your system wiring by daisy-chaining your RS fans and connecting them to a single 4-pin PWM fan header on your motherboard.
SHH… SILENT POWER
QUIET AND EFFICIENT
The efficient, low-noise pump circulates coolant with a high flow rate at a whisper-quiet 20 dBA. PWM control lets you set your fan speed up to 2,100 RPM, with support for Zero RPM mode for quiet operation.
| Performance | |
|---|---|
| Suitable location | Processor |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 2100 RPM |
| Noise level (high speed) | 34 dB |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Maximum airflow | 74.37 cfm |
| Maximum air pressure | 4.91 mmH2O |
| Number of fans | 2 fan(s) |
| Quantity per pack | 1 pc(s) |
| Design | |
| Number of fans | 2 fan(s) |
| Product colour | White |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan controller | Yes |
| Technical details | |
| Noise level (high speed) | 34 dB |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Maximum airflow | 74.37 cfm |
| Maximum air pressure | 4.91 mmH2O |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 275 mm |
| Height | 125 mm |
| Weight | 1.93 kg |
| Radiator width | 24 cm |
iCUE LINK TITAN 240 RX LCD Liquid CPU Cooler - White
The CORSAIR iCUE LINK TITAN RX LCD delivers high-performance, ultra-quiet cooling with optimized thermal performance, streamlined iCUE LINK connectivity, and dynamic RGB lighting.
iCUE LINK TITAN RX LCD
HIGH-PERFORMANCE AIO CPU COOLER WITH RGB FANS
BRILLIANT IPS LCD DISPLAY
The custom 2.1″ 480x480 LCD screen can be controlled via iCUE, enabling you to select from 16.7 million custom colors or choose from pre-defined animations and data displays. It now includes full in-app GIPHY integration, giving you access to thousands of your favorite memes and GIFs.
DISPLAY SCREEN PREVIEW
- APERTURE
- CONCENTRIC
- CUSTOM 1
- CUSTOM 2
- CUSTOM 3
LIGHTING PROFILES
- WATERCOLOR SPECTRUM
- SPIRAL RAINBOW
- AND MORE
IT'S COOLER AT THE TOP
POWERFUL AND EFFICIENT ALL-IN-ONE CPU COOLING
For cutting-edge systems that need to get the most out their CPUs, the TITAN RX LCD towers above the competition. Thousands of hours of in-house engineering culminate in a CPU cooler that combines unparalleled performance, impressively quiet acoustics, and simplified iCUE LINK connections.
THE FUTURE OF DIY BUILDING
iCUE LINK SMART COMPONENT ECOSYSTEM
- EVERYTHING IN ONE PLACE
Manage the lighting and performance for all of your components and peripherals.
- ONE CABLE. ONE CONNECTOR.
Link your components to each other in any order with a universal connector. If you can plug it in, it'll work.
- MODULAR CONTROL SOFTWARE
Fine-tune your component settings and see all PC sensor data from an intuitive interface.
PERFORMANCE WHERE IT MATTERS
PEAK COOLING POWER
Push airflow through radiators like never before at low, medium, and high speeds. RX Series fans deliver high airflow and static pressure, while keeping noise as low as possible.
ENGINEERED FOR GREATNESS
FLOWDRIVE COOLING ENGINE
Designed in-house by CORSAIR's expert engineers, the pump is powered by a three-phase motor with a higher flow rate and even lower noise levels than its predecessors. Add to that a precision-engineered cold plate surface profile that maximizes contact with your CPU’s IHS, and you have a recipe for consistently lower temperatures.
MAKE IT PERSONAL
CAPSWAP MODULAR DESIGN
It's never been easier to change the look or functionality of your AIO. Switch the default pump cap with any CapSwap module (sold separately) in seconds, completely tool-free, and it's almost like a brand-new cooler.
WIDE COMPATIBILITY
EASY INSTALLATION FOR INTEL AND AMD CPUs
Includes mounting brackets and backplates for fast installation on a wide range of socket types, including modern Intel LGA 1851/1700 and AMD AM5/AM4.
KEEPING UP APPEARANCES
YOUR COOLER HAS NEVER LOOKED COOLER
- PUMP CAP
The TITAN RX LCD’s unique pump cap design shows off the lighting from 44 individually addressable RGB LEDs around the pump.
- DETACHABLE SIDE PLATES
Each RX RGB fan comes with a pair of decorative side plates, providing a choice between a translucent window or a CORSAIR wordmark.
- FAN LIGHTING
Eight individually addressable RGB LEDs per fan display mesmerizing effects, easily synchronized with your pump lighting.
EXTREME PERFORMANCE THERMAL PASTE
For top-notch performance, every detail in the heat transfer and dissipation chain matters.
All TITAN RX LCD CPU blocks include pre-applied CORSAIR XTM70 Extreme Performance Thermal Paste for maximum heat transfer from your high-end processor to the cooler cold plate.
| Performance | |
|---|---|
| Suitable location | Processor |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 2100 RPM |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 2 fan(s) |
| Quantity per pack | 1 pc(s) |
| Fan static pressure | 4.33 mmH2O |
| Design | |
| Number of fans | 2 fan(s) |
| Product colour | White |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan controller | Yes |
| Technical details | |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 125 mm |
| Height | 275 mm |
| Weight | 2.07 kg |
| Radiator width | 27.7 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
Great performance and impressive lighting
The Light Wings LX 140mm PWM boasts optimized fan blades and an illuminated impeller for great performance and lighting.
SHOW WHAT YOU GOT
A fan made for show cases
Light Wings LX 140mm PWM undeniably upgrades all kind of PC cases with its spectacular lighting. Especially show cases with an emphasis on ARGB illumination benefit from this fan. Add a bunch of them to your showcase and let friends and family gaze in awe.
IMPRESSIVE LIGHTING
Lots of illumination possibilities
16 LEDs are located inside the hub of the impeller of the Light Wings LX 140mm PWM and shine outwards onto the frosted fan blades. This creates an unmistakable look and enables you to express your creativity.
YOUR CASE FAN OF CHOICE
Optimized fan blades and frame
Light Wings LX 140mm PWM features a fan frame outlet that minimizes air leaks. In addition, the fan blades are optimized for maximum airflow, making this fan the best-in-class choice for virtually any case configuration.
DAISY CHAIN IT!
One connector for all your Light Wings LX fans
The ARGB connection cable comes with an input and an output connector. The input can be used to connect the fan to your motherboard or to an ARGB controller, but also to daisy-chain it with the output connector of other Light Wings LX fans.
RIFLE BEARING TECHNOLOGY
Makes Light Wings LX a long-lasting companion
Light Wings LX 140mm PWM is built to last. With the proven rifle bearing technology, on average, this fan offers a lifespan of 60,000 hours.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1200 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 22.9 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 56 cfm |
| Maximum air pressure | 0.9 mmH2O |
| Airflow | 95 m³/h |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 1 pc(s) |
| Number of fan blades | 7 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 1 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 7 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 22.9 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 56 cfm |
| Maximum air pressure | 0.9 mmH2O |
| Airflow | 95 m³/h |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.3 A |
| Fan current | 0.09 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 140 x 140 x 25 mm |
| Package depth | 184 mm |
| Package width | 142 mm |
| Package height | 27 mm |
| Fan weight | 165 g |
| Package weight | 200 g |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 184 mm |
| Package width | 142 mm |
| Package height | 27 mm |
| Package weight | 200 g |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 4 |
| Logistics data | |
| Shipping (inner) case width | 37.8 cm |
| Shipping (inner) case length | 49.4 cm |
| Shipping (inner) case height | 33 cm |
| Shipping (inner) case gross weight | 15.8 kg |
| Products per shipping (inner) case | 72 pc(s) |
iCUE LINK TITAN 360 RX LCD Liquid CPU Cooler
The CORSAIR iCUE LINK TITAN RX LCD delivers high-performance, ultra-quiet cooling with optimized thermal performance, streamlined iCUE LINK connectivity, and dynamic RGB lighting.
iCUE LINK TITAN RX LCD
HIGH-PERFORMANCE AIO CPU COOLER WITH RGB FANS
BRILLIANT IPS LCD DISPLAY
The custom 2.1″ 480x480 LCD screen can be controlled via iCUE, enabling you to select from 16.7 million custom colors or choose from pre-defined animations and data displays. It now includes full in-app GIPHY integration, giving you access to thousands of your favorite memes and GIFs.
DISPLAY SCREEN PREVIEW
- APERTURE
- CONCENTRIC
- CUSTOM 1
- CUSTOM 2
- CUSTOM 3
LIGHTING PROFILES
- WATERCOLOR SPECTRUM
- SPIRAL RAINBOW
- AND MORE
IT'S COOLER AT THE TOP
POWERFUL AND EFFICIENT ALL-IN-ONE CPU COOLING
For cutting-edge systems that need to get the most out their CPUs, the TITAN RX LCD towers above the competition. Thousands of hours of in-house engineering culminate in a CPU cooler that combines unparalleled performance, impressively quiet acoustics, and simplified iCUE LINK connections.
THE FUTURE OF DIY BUILDING
iCUE LINK SMART COMPONENT ECOSYSTEM
- EVERYTHING IN ONE PLACE
Manage the lighting and performance for all of your components and peripherals.
- ONE CABLE. ONE CONNECTOR.
Link your components to each other in any order with a universal connector. If you can plug it in, it'll work.
- MODULAR CONTROL SOFTWARE
Fine-tune your component settings and see all PC sensor data from an intuitive interface.
PERFORMANCE WHERE IT MATTERS
PEAK COOLING POWER
Push airflow through radiators like never before at low, medium, and high speeds. RX Series fans deliver high airflow and static pressure, while keeping noise as low as possible.
ENGINEERED FOR GREATNESS
FLOWDRIVE COOLING ENGINE
Designed in-house by CORSAIR's expert engineers, the pump is powered by a three-phase motor with a higher flow rate and even lower noise levels than its predecessors. Add to that a precision-engineered cold plate surface profile that maximizes contact with your CPU’s IHS, and you have a recipe for consistently lower temperatures.
MAKE IT PERSONAL
CAPSWAP MODULAR DESIGN
It's never been easier to change the look or functionality of your AIO. Switch the default pump cap with any CapSwap module (sold separately) in seconds, completely tool-free, and it's almost like a brand-new cooler.
WIDE COMPATIBILITY
EASY INSTALLATION FOR INTEL AND AMD CPUs
Includes mounting brackets and backplates for fast installation on a wide range of socket types, including modern Intel LGA 1851/1700 and AMD AM5/AM4.
KEEPING UP APPEARANCES
YOUR COOLER HAS NEVER LOOKED COOLER
- PUMP CAP
The TITAN RX LCD’s unique pump cap design shows off the lighting from 44 individually addressable RGB LEDs around the pump.
- DETACHABLE SIDE PLATES
Each RX RGB fan comes with a pair of decorative side plates, providing a choice between a translucent window or a CORSAIR wordmark.
- FAN LIGHTING
Eight individually addressable RGB LEDs per fan display mesmerizing effects, easily synchronized with your pump lighting.
EXTREME PERFORMANCE THERMAL PASTE
For top-notch performance, every detail in the heat transfer and dissipation chain matters.
All TITAN RX LCD CPU blocks include pre-applied CORSAIR XTM70 Extreme Performance Thermal Paste for maximum heat transfer from your high-end processor to the cooler cold plate.
| Performance | |
|---|---|
| Suitable location | Processor |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 2100 RPM |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 3 fan(s) |
| Quantity per pack | 1 pc(s) |
| Fan static pressure | 4.33 mmH2O |
| Design | |
| Number of fans | 3 fan(s) |
| Product colour | Black |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan controller | Yes |
| Technical details | |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 3 fan(s) |
| Illumination LED | Yes |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 125 mm |
| Height | 396 mm |
| Weight | 2.59 kg |
| Radiator width | 39.6 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 45 cm |
DIRECT-TO-MOTHERBOARD CONNECTION
Skip the fan hubs and excessive cables – daisy-chain your RS Series fans in sequence and control them all through just a single 4-pin PWM connector on your motherboard.
AIRFLOW AND STATIC PRESSURE
A better fan relies on several key features, each improving how it handles air pressure and airflow as a radiator or case fan. RS fans were engineered to excel at both.
BLADE SHAPE
Optimized angle of attack, airfoil shape, and edge curvature ensure maximum airflow efficiency.
FAN HOUSING
The fan housing was designed to support the largest possible blade radius within its size limit.
CORSAIR AIRGUIDE
Stator vanes are angled to focus the exhaust airflow cone and improve the coverage of radiator fins and heat dissipation.
EVERY SOURCE OF NOISE ADDRESSED
MAGNETIC DOME BEARING
This improved bearing minimizes friction and mechanical noise, achieving a balance between high airflow performance and low acoustic footprint. On top of that, the reduced friction means greater longevity for your fan.
STRENGTH IN NUMBERS
PROVEN COOLING PERFORMANCE
RS fans have undergone months of extensive testing to guarantee exceptional performance at the full range of PWM fan speeds set with their direct-to-motherboard connection.
Read more about how radiator fan performance is actually measured, what the specifications mean in practice and what separates good fans from great fans.
ZERO RPM MODE
PWM control lets you precisely set fan speeds so your fans only spin as fast as they need to, resulting in less fan noise overall, while support for Zero RPM means they can stop spinning completely at low loads to eliminate fan noise.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (min) | 420 RPM |
| Rotational speed (max) | 2100 RPM |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Minimum airflow (imperial) | 13.3 cfm |
| Maximum airflow | 72.8 cfm |
| Minimum air pressure | 0.2 mmH2O |
| Maximum air pressure | 4.15 mmH2O |
| Number of fans | 3 fan(s) |
| Quantity per pack | 3 pc(s) |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Product colour | White |
| Technical details | |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Minimum airflow (imperial) | 13.3 cfm |
| Maximum airflow | 72.8 cfm |
| Minimum air pressure | 0.2 mmH2O |
| Maximum air pressure | 4.15 mmH2O |
| Number of fans | 3 fan(s) |
| Fan connector | 4-pin |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Fan current | 0.4 A |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Fan weight | 704 g |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
Quiet. Cool. Refined.
Experience exceptional cooling performance and quiet operation. Powered by a robust three-phase motor and Alphacool Apex Stealth Metal Power fans, the ProArt LC 360 expertly integrates premium tech into an elegantly understated design. An illuminated meter on the pump cover also provides live system stats in the signature minimalist ProArt manner for real-time information at a glance. And its subtle and graceful aesthetics add a touch of refinement to your setup. Cool, quiet and classy—the perfect trifecta for any and all content creators.
Illuminated Meter
An innovative illuminated meter to display real-time PC build information, such as system load, temperatures, and fan speeds, allowing for a quick glance to understand the system's status.
Alphacool Apex Stealth Metal Power Fan
To overcome the thermal challenges of the latest multi-core CPUs, the ProArt LC 360 offers Alphacool Apex Stealth Metal 120 mm radiator fans that deliver high performance and minimized noise.
Performance 3-Phase Motor Pump
High-performance three-phase motor offers excellent cooling capability and quieter operation.
450 mm Durable Tubing
This tubing features a braided mesh sleeve for durability, and 450 mm of length for additional flexibility and chassis compatibility.
Stylish Radiator
The understated and refined radiator styling enhances the aesthetic of your entire build.
Extensive Compatibility
The ProArt LC 360 features 450 mm of tubing and is compatible with a wide range of Intel® and AMD motherboard platforms, giving you ample processor and build flexibility.
| Performance | |
|---|---|
| Suitable location | Processor |
| Rotational speed (min) | 800 RPM |
| Rotational speed (max) | 2200 RPM |
| Noise level | 35.7 sone |
| Number of heat pipes | 2 |
| Type | Liquid cooling kit |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 102.3 cfm |
| Maximum air pressure | 3.2 mmH2O |
| Number of fans | 3 fan(s) |
| Number of fan blades | 9 |
| Fan noise level (max) | 35.7 dB |
| Fan speed (min) | 800 RPM |
| Fan speed (max) | 2200 RPM |
| Design | |
| Number of heat pipes | 2 |
| Number of fans | 3 fan(s) |
| Product colour | Black |
| Number of fan blades | 9 |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Technical details | |
| Number of heat pipes | 2 |
| Type | Liquid cooling kit |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Maximum airflow | 102.3 cfm |
| Maximum air pressure | 3.2 mmH2O |
| Number of fans | 3 fan(s) |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 182.5 mm |
| Package width | 462 mm |
| Package height | 2025 mm |
| Package weight | 3.32 kg |
| Weight | 2.19 kg |
| Radiator width | 12.1 cm |
| Radiator depth | 39.4 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Waterblock width | 7.8 cm |
| Waterblock depth | 7.8 cm |
| Waterblock height | 2.7 cm |
| Packaging data | |
| Package depth | 182.5 mm |
| Package width | 462 mm |
| Package height | 2025 mm |
| Package weight | 3.32 kg |
Great performance and impressive lighting
The Light Wings LX 120mm PWM White Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1600 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 7 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | White |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 7 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 25.5 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 51.5 cfm |
| Maximum air pressure | 1.34 mmH2O |
| Airflow | 87.5 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.32 A |
| Fan power consumption | 3.8 W |
| Fan voltage | 12 V |
| Fan current | 0.1 A |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Fan weight | 133 g |
| Package weight | 470 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Package weight | 470 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 26.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 32 cm |
| Shipping (inner) case gross weight | 10.2 kg |
| Products per shipping (inner) case | 20 pc(s) |
Great performance and impressive lighting
The Light Wings LX 120mm PWM high-speed boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 2100 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 30.9 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 61.8 cfm |
| Maximum air pressure | 2.51 mmH2O |
| Airflow | 105.1 m³/h |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 1 pc(s) |
| Number of fan blades | 9 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 1 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 9 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 30.9 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 61.8 cfm |
| Maximum air pressure | 2.51 mmH2O |
| Airflow | 105.1 m³/h |
| Number of fans | 1 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.45 A |
| Fan power consumption | 5.4 W |
| Fan voltage | 12 V |
| Fan current | 0.15 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 27 mm |
| Width | 120 mm |
| Package weight | 210 g |
| Depth | 120 mm |
| Height | 25 mm |
| Weight | 135 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 27 mm |
| Package weight | 210 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 4 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 31.9 cm |
| Shipping (inner) case length | 43.3 cm |
| Shipping (inner) case height | 29 cm |
| Shipping (inner) case gross weight | 10.9 kg |
| Products per shipping (inner) case | 60 pc(s) |
TRANQUIL & POWERFUL
Unique fan blade and frame design offers powerful airflow with low noise accomplished.
EXQUISITE CRAFTSMANSHIP
Minimal clearance between fan frame and blades, achieving maximum operational efficiency.
Fluid Dynamic Bearing
Reduces friction between shaft and bearing for longer life and minimal noise.
VIBRATION-ABSORBING & ANTI-NOISE PADS
Equipped with eight damping feet to prevent resonance, reducing noise effectively.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Type | Fan |
| Fan diameter | 14 cm |
| Minimum airflow (imperial) | 21.13 cfm |
| Maximum airflow | 85.96 cfm |
| Minimum air pressure | 0.11 mmH2O |
| Maximum air pressure | 1.79 mmH2O |
| Quantity per pack | 1 pc(s) |
| Fan noise level (min) | 18.6 dB |
| Fan noise level (max) | 27.5 dB |
| Fan speed (min) | 450 RPM |
| Fan speed (max) | 1500 RPM |
| Fan's mean time to failure (MTTF) | 50000 h |
| Design | |
| Fan connector | 4-pin |
| Product colour | Black |
| Technical details | |
| Type | Fan |
| Fan diameter | 14 cm |
| Minimum airflow (imperial) | 21.13 cfm |
| Maximum airflow | 85.96 cfm |
| Minimum air pressure | 0.11 mmH2O |
| Maximum air pressure | 1.79 mmH2O |
| Fan connector | 4-pin |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 7 - 13.8 V |
| Rated current | 0.12 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 25 mm |
| Height | 140 mm |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Cables included | 4-pin |
| Package type | Box |
Great performance and impressive lighting
The Light Wings LX 140mm PWM high-speed White Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1800 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 9 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | White |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 9 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.45 A |
| Fan power consumption | 5.4 W |
| Fan voltage | 12 V |
| Fan current | 0.18 A |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 140 x 140 x 25 mm |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Fan weight | 169 g |
| Package weight | 590 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 184 mm |
| Package width | 80 mm |
| Package height | 142 mm |
| Package weight | 590 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 30.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 36 cm |
| Shipping (inner) case gross weight | 12.6 kg |
| Products per shipping (inner) case | 20 pc(s) |
NAUTILUS 360 RS ARGB Liquid CPU Cooler - White
The CORSAIR NAUTILUS RS ARGB Liquid CPU Cooler delivers efficient, low-noise cooling with straightforward connectivity – no controller required, just plugs directly into your motherboard.
COOL, QUIET, POWERFUL SIMPLE, FOCUSED PERFORMANCE
Renowned CORSAIR engineering delivers high-performance, low-noise cooling, enabling your CPU to reach its full potential.
MADE TO FIT MAXIMUM CONTACT
The slightly convex design ensures optimal contact with your CPU’s integrated heat spreader, with thermal paste applied in an optimized pattern to speed up installation.
FOCUSED AIRFLOW
HIGH AIRFLOWAND STATICPRESSURE
RS120 ARGB Fans deliver powerful airflow with high static pressure to push air through the radiator. CORSAIR AirGuide technology and Magnetic Dome bearings ensure excellent cooling performance while keeping noise to a minimum.
STAY CONNECTED
DAISY-CHAINEDCONNECTIONS
Simplify your system wiring by daisy-chaining your RS fans and connecting them to a single 4-pin PWM fan header on your motherboard.
SHH… SILENT POWER
QUIET AND EFFICIENT
The efficient, low-noise pump circulates coolant with a high flow rate at a whisper-quiet 20 dBA. PWM control lets you set your fan speed up to 2,100 RPM, with support for Zero RPM mode for quiet operation.
| Performance | |
|---|---|
| Suitable location | Processor |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 2100 RPM |
| Noise level (high speed) | 34 dB |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Maximum airflow | 74.37 cfm |
| Maximum air pressure | 4.91 mmH2O |
| Number of fans | 2 fan(s) |
| Quantity per pack | 1 pc(s) |
| Design | |
| Number of fans | 2 fan(s) |
| Product colour | Black |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan controller | Yes |
| Technical details | |
| Noise level (high speed) | 34 dB |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Maximum airflow | 74.37 cfm |
| Maximum air pressure | 4.91 mmH2O |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 275 mm |
| Height | 125 mm |
| Weight | 1.93 kg |
| Radiator width | 24 cm |
iCUE LINK TITAN 360 RX LCD Liquid CPU Cooler - White
The CORSAIR iCUE LINK TITAN RX LCD delivers high-performance, ultra-quiet cooling with optimized thermal performance, streamlined iCUE LINK connectivity, and dynamic RGB lighting.
iCUE LINK TITAN RX LCD
HIGH-PERFORMANCE AIO CPU COOLER WITH RGB FANS
BRILLIANT IPS LCD DISPLAY
The custom 2.1″ 480x480 LCD screen can be controlled via iCUE, enabling you to select from 16.7 million custom colors or choose from pre-defined animations and data displays. It now includes full in-app GIPHY integration, giving you access to thousands of your favorite memes and GIFs.
DISPLAY SCREEN PREVIEW
- APERTURE
- CONCENTRIC
- CUSTOM 1
- CUSTOM 2
- CUSTOM 3
LIGHTING PROFILES
- WATERCOLOR SPECTRUM
- SPIRAL RAINBOW
- AND MORE
IT'S COOLER AT THE TOP
POWERFUL AND EFFICIENT ALL-IN-ONE CPU COOLING
For cutting-edge systems that need to get the most out their CPUs, the TITAN RX LCD towers above the competition. Thousands of hours of in-house engineering culminate in a CPU cooler that combines unparalleled performance, impressively quiet acoustics, and simplified iCUE LINK connections.
THE FUTURE OF DIY BUILDING
iCUE LINK SMART COMPONENT ECOSYSTEM
- EVERYTHING IN ONE PLACE
Manage the lighting and performance for all of your components and peripherals.
- ONE CABLE. ONE CONNECTOR.
Link your components to each other in any order with a universal connector. If you can plug it in, it'll work.
- MODULAR CONTROL SOFTWARE
Fine-tune your component settings and see all PC sensor data from an intuitive interface.
PERFORMANCE WHERE IT MATTERS
PEAK COOLING POWER
Push airflow through radiators like never before at low, medium, and high speeds. RX Series fans deliver high airflow and static pressure, while keeping noise as low as possible.
ENGINEERED FOR GREATNESS
FLOWDRIVE COOLING ENGINE
Designed in-house by CORSAIR's expert engineers, the pump is powered by a three-phase motor with a higher flow rate and even lower noise levels than its predecessors. Add to that a precision-engineered cold plate surface profile that maximizes contact with your CPU’s IHS, and you have a recipe for consistently lower temperatures.
MAKE IT PERSONAL
CAPSWAP MODULAR DESIGN
It's never been easier to change the look or functionality of your AIO. Switch the default pump cap with any CapSwap module (sold separately) in seconds, completely tool-free, and it's almost like a brand-new cooler.
WIDE COMPATIBILITY
EASY INSTALLATION FOR INTEL AND AMD CPUs
Includes mounting brackets and backplates for fast installation on a wide range of socket types, including modern Intel LGA 1851/1700 and AMD AM5/AM4.
KEEPING UP APPEARANCES
YOUR COOLER HAS NEVER LOOKED COOLER
- PUMP CAP
The TITAN RX LCD’s unique pump cap design shows off the lighting from 44 individually addressable RGB LEDs around the pump.
- DETACHABLE SIDE PLATES
Each RX RGB fan comes with a pair of decorative side plates, providing a choice between a translucent window or a CORSAIR wordmark.
- FAN LIGHTING
Eight individually addressable RGB LEDs per fan display mesmerizing effects, easily synchronized with your pump lighting.
EXTREME PERFORMANCE THERMAL PASTE
For top-notch performance, every detail in the heat transfer and dissipation chain matters.
All TITAN RX LCD CPU blocks include pre-applied CORSAIR XTM70 Extreme Performance Thermal Paste for maximum heat transfer from your high-end processor to the cooler cold plate.
| Performance | |
|---|---|
| Suitable location | Processor |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 2100 RPM |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 3 fan(s) |
| Quantity per pack | 1 pc(s) |
| Fan static pressure | 4.33 mmH2O |
| Design | |
| Number of fans | 3 fan(s) |
| Product colour | White |
| Illumination LED | Yes |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan controller | Yes |
| Technical details | |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 36 dB |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Minimum airflow (imperial) | 10.4 cfm |
| Maximum airflow | 73.5 cfm |
| Number of fans | 3 fan(s) |
| Illumination LED | Yes |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 125 mm |
| Height | 396 mm |
| Weight | 2.59 kg |
| Radiator width | 39.6 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 45 cm |
Great performance and impressive lighting
The Light Wings LX 140mm PWM high-speed boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 1800 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 1 pc(s) |
| Number of fan blades | 9 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 1 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 9 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 30.5 dB |
| Type | Fan |
| Fan diameter | 14 cm |
| Maximum airflow | 75.3 cfm |
| Maximum air pressure | 2.45 mmH2O |
| Airflow | 127.9 m³/h |
| Number of fans | 1 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.45 A |
| Fan power consumption | 5.4 W |
| Fan voltage | 12 V |
| Fan current | 0.18 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Package depth | 184 mm |
| Package width | 142 mm |
| Package height | 27 mm |
| Width | 140 mm |
| Package weight | 210 g |
| Depth | 140 mm |
| Height | 25 mm |
| Weight | 169 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 184 mm |
| Package width | 142 mm |
| Package height | 27 mm |
| Package weight | 210 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 4 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 37.8 cm |
| Shipping (inner) case length | 49.4 cm |
| Shipping (inner) case height | 33 cm |
| Shipping (inner) case gross weight | 16.1 kg |
| Products per shipping (inner) case | 72 pc(s) |
Great performance and impressive lighting
The Light Wings LX 120mm PWM high-speed Triple Pack boasts optimized fan blades and an illuminated impeller for great performance and lighting.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (max) | 2100 RPM |
| Bearing type | Rifle bearing |
| Noise level (high speed) | 30.9 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 61.8 cfm |
| Maximum air pressure | 2.51 mmH2O |
| Airflow | 105.1 m³/h |
| Number of fans | 3 fan(s) |
| Mean time between failures (MTBF) | 60000 h |
| Quantity per pack | 3 pc(s) |
| Number of fan blades | 9 |
| Design | |
| Fan connector | 4-pin |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Cable length | 0.5 m |
| Illumination LED | Yes |
| Number of LEDs | 16 |
| Number of fan blades | 9 |
| LED connector type | 3-pin |
| Technical details | |
| Noise level (high speed) | 30.9 dB |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 61.8 cfm |
| Maximum air pressure | 2.51 mmH2O |
| Airflow | 105.1 m³/h |
| Number of fans | 3 fan(s) |
| Cable length | 0.5 m |
| Fan connector | 4-pin |
| Illumination LED | Yes |
| Warranty period | 3 year(s) |
| Compliance certificates | CE, RoHS, UKCA, WEEE |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Rated voltage | 12 V |
| Voltage | 5 - 13.2 V |
| Maximum current | 0.45 A |
| Fan power consumption | 5.4 W |
| Fan voltage | 12 V |
| Fan current | 0.15 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Fan weight | 135 g |
| Package weight | 480 g |
| Cable length | 0.5 m |
| Endurance | |
| Mean time between failures (MTBF) | 60000 h |
| Packaging data | |
| Package depth | 164 mm |
| Package width | 122 mm |
| Package height | 80 mm |
| Package weight | 480 g |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Screws included | Yes |
| Number of screws | 12 |
| Package type | Box |
| Logistics data | |
| Shipping (inner) case width | 26.9 cm |
| Shipping (inner) case length | 42.8 cm |
| Shipping (inner) case height | 32 cm |
| Shipping (inner) case gross weight | 10.3 kg |
| Products per shipping (inner) case | 20 pc(s) |
NFINITY ELEGANCE, COOLING MASTERY
Combining cooling performance, easy installation, and aesthetics all in one. The Prime LC 240 ARGB features a specially designed CPU contact area that can effectively cool the CPU and provide stable performance. At the same time, it comes with pre-installed ARGB fans that optimize the user's PC DIY experience. A single cable connects the lighting and fans, making cable management much easier. The customizable infinity mirror lenses in the water block give the PC build more versatility, empowering you to create diverse styles.
Specially designed CPU contact area
The larger contact area allows for more efficient heat transfer from the CPU to the cooler. This helps ensure the CPU maintains optimal operating temperatures even under heavy workloads, without experiencing thermal throttling or performance degradation.
| Performance | |
|---|---|
| Suitable location | Computer case |
| Pulse-width modulation (PWM) support | Yes |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Number of fans | 2 fan(s) |
| Fan static pressure | 3.2 mmH2O |
| Fan speed (min) | 1900 RPM |
| Fan speed (max) | 2500 RPM |
| Design | |
| Number of fans | 2 fan(s) |
| Illumination colour | Multi |
| Product colour | Black |
| Illumination LED | Yes |
| Water block material | Copper |
| Technical details | |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5 |
| Number of fans | 2 fan(s) |
| Noise level | 37.6 dB |
| Illumination LED | Yes |
| Warranty period | 6 year(s) |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 240 x 123 x 25 mm |
| Package depth | 232 mm |
| Package width | 306.1 mm |
| Package height | 146.5 mm |
| Package weight | 1.45 kg |
| Weight | 890 g |
| Radiator width | 27.7 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Waterblock width | 6.51 cm |
| Waterblock depth | 6.06 cm |
| Waterblock height | 6.85 cm |
| Packaging data | |
| Package depth | 232 mm |
| Package width | 306.1 mm |
| Package height | 146.5 mm |
| Package weight | 1.45 kg |
| Package type | Box |
| Indication | |
| Illumination colour | Multi |
| Packaging content | |
| Package type | Box |
| Other features | |
| Noise level | 37.6 dB |
| Fan performance | 75.7 cfm |
