1 GHz Dual-Core CPU, 3× 10/100/1000 Mbps RJ45, 2.4/5 GHz, 802.11ax, 3G/4G/5G, 99 x 99 x 192mm
Enjoy WiFi and Phone Calls All in One 5G Router
5G AX3000 Wi-Fi6 Telephony Router
Unrivaled Speed with 5G, Revolutionary Experience
5G greatly boosts the download speed up to 3.4 Gbps–22x faster than 4G LTE. It brings fast responsive network connections to tomorrow’s mobile devices, with only 1 ms latency.
Plug and Play, Enjoy 5G Network Everywhere
Simple, just one SIM card
Traditional broadband or cable installation is expensive and time-consuming for your vacation home, farm, or suburban warehouse. Long contract periods also create headaches for short-rentals, pop-up venues, and temporary shops to access the internet. NX510v ensures a comfortable and no-block network installation. Plug in your SIM card and enjoy high-speed internet!
AX3000 – Powerful Wi-Fi 6
Armed with WiFi 6 technology, NX510v is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh WiFi to enjoy the future network that loads faster and connects more.
Enjoy WiFi and Phone Calls Simultaneously
NX510v is not only a WiFi router and modem combo, but also a phone. It has a phone port to connect your existing landline phone so that you can make phone calls and surf the internet at the same time. Moreover, various voice functions are supported including VoLTE and CSFB. Simply enjoy a professional and high-quality voice call as you like.
Create Smart Mesh WiFi with Great Flexibility
Working with other EasyMesh-compatible devices, NX510v creates a unified mesh WiFi network for seamless whole home coverage. No more searching for a stable connection.
Engineered for More Devices
NX510v is aimed to dramatically improve capacity and efficiency in traffic-dense environments. No matter how many screens or devices are on at once, everyone is able to enjoy a more efficient network that loads faster without dragging down performance.
Available WAN Connection
The WAN/LAN port enables NX510v to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 5G/4G connection works as a backup to provide a sustained and reliable internet connection for you.
Easy Setup and Use
You can set up your device in minutes, whether you prefer the powerful Aginet app or the intuitive web interface. The Aginet app allows you to manage your network from a smartphone or tablet.
Aginet Solution:End-to-End Management System for ISPs
The Aginet Solution offers ISPs powerful and flexible platforms to manage multiple devices for connected homes, such as dynamic service provisioning, remote firmware upgrading, and troubleshooting.
| WAN connection |
|---|
| WAN connection type |
RJ-45 |
| 3G/4G USB modem compatibility |
Yes |
| SIM card slot |
Yes |
| DSL WAN |
Yes |
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| WLAN data transfer rate (second band) |
2402 Mbit/s |
| WLAN data transfer rate (first band) |
574 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) |
3000 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Network |
|---|
| Dynamic DNS (DDNS) |
Yes |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Mobile network |
|---|
| 4G standard |
LTE-TDD & LTE-FDD |
| 3G standards |
DC-HSDPA, HSDPA, HSPA+, HSUPA, WCDMA |
| Mobile network generation |
5G |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
3 |
| Management features |
|---|
| Quality of Service (QoS) support |
Yes |
| Security |
|---|
| Parental control |
Yes |
| Design |
|---|
| LED indicators |
LAN, LTE, Status |
| Product colour |
White |
| Product type |
Tabletop router |
| Packaging content |
|---|
| Quick start guide |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Antenna |
|---|
| Antenna design |
Internal & external |
| Features |
|---|
| Certification |
CE, RoHS |
| Processor cores |
2 |
| Processor frequency |
1000 MHz |
| Built-in processor |
Yes |
| Power |
|---|
| Output current |
2 A |
| Output voltage |
12 V |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power source type |
AC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
99 mm |
| Depth |
99 mm |
| Height |
192 mm |
