| Processor | |
|---|---|
| Processor number of cores supported | 10 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®, Intel® Xeon® |
| Processor socket | LGA 1200 (Socket H5) |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 128 GB |
| Supported memory module capacities | 4GB, 8GB, 16GB, 32GB |
| Supported memory clock speeds | 2133,2400,2666,2933 MHz |
| Non-ECC | Yes |
| ECC | Yes |
| Memory voltage | 1.2 V |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Supported memory types | DDR4-SDRAM |
| Storage controllers | |
|---|---|
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| Supported storage drive interfaces | Serial ATA III, SATA III |
| Internal I/O | |
|---|---|
| Number of COM connectors | 2 |
| TPM connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
| USB 2.0 connectors | 6 |
| Rear panel I/O ports | |
|---|---|
| DisplayPorts quantity | 2 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| Network | |
|---|---|
| LAN controller | Intel® I210-AT, Intel® I219-LM |
| Ethernet LAN | Yes |
| Features | |
|---|---|
| Audio chip | Realtek ALC888S |
| Motherboard chipset | Intel W480 |
| Motherboard chipset family | Intel |
| Motherboard form factor | micro ATX |
| Component for | PC |
| Expansion slots | |
|---|---|
| PCI Express x16 (Gen 3.x) slots | 1 |
| BIOS | |
|---|---|
| System Management BIOS (SMBIOS) version | 3.1 |
| ACPI version | 6.1 |
| BIOS type | UEFI AMI |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 10 - 85% |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Weight & dimensions | |
|---|---|
| Depth | 243.8 mm |
| Width | 243.8 mm |
| Other features | |
|---|---|
| Number of DIMM slots | 4 |
| Number of processors supported | 1 |
| PCI Express x4 (Gen 3.x) slots | 2 |
