| Audio |
|---|
| Built-in speaker(s) |
No |
| Performance |
|---|
| Built-in speaker(s) |
No |
| Built-in microphone |
No |
| Built-in camera |
No |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Windows operating systems supported |
Windows 10, Windows 11 |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colours |
| Native aspect ratio |
16:9 |
| Pixel density |
95 ppi |
| Colour gamut |
99% |
| Maximum refresh rate |
120 Hz |
| sRGB coverage (typical) |
99% |
| HD type |
Full HD |
| Display technology |
LCD |
| Contrast ratio (dynamic) |
3000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
6 ms |
| Display diagonal |
60.5 cm (23.8") |
| Contrast ratio (typical) |
1500:1 |
| Response time (fast) |
4 ms |
| Touchscreen |
No |
| Panel type |
IPS |
| Colour depth |
8 bit |
| LED backlight |
Yes |
| Colour gamut standard |
Rec. 709 |
| Anti-glare screen |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
No |
| Built-in microphone |
No |
| Built-in camera |
No |
| Power |
|---|
| Power cable length |
1.8 m |
| Power supply type |
Internal |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
66 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
12 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
C |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
12 kWh |
| Design |
|---|
| Feet colour |
Black |
| Certification |
ENERGY STAR Certified, TCO 10.0, TCO Edge 2.1, EPEAT Gold, RoHS, EU Energy Efficiency Level (Level-C) Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Flicker Free, TÜV Low Blue Light, TÜV Rheinland Eye Comfort (5 Stars) |
| Product colour |
Black |
| Colour name |
Raven Black |
| Camera |
|---|
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-B |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
3 |
| USB Type-C downstream ports quantity |
1 |
| Headphone out |
No |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
15 W |
| Number of USB Type-B upstream ports quantity |
1 |
| DisplayPort out quantity |
0 |
| Technical details |
|---|
| Height (without stand) |
314.8 mm |
| Depth (without stand) |
45.3 mm |
| Width (without stand) |
539.8 mm |
| Feet colour |
Black |
| Cable lock slot |
Yes |
| HDMI |
Yes |
| Built-in microphone |
No |
| Product colour |
Black |
| Power supply type |
Internal |
| Weight (with stand) |
5.1 kg |
| Touchscreen |
No |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 11 |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 23° |
| Pivot |
Yes |
| Pivot angle |
-90 - 90° |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
15.5 cm |
| Weight & dimensions |
|---|
| Height (without stand) |
314.8 mm |
| Depth (without stand) |
45.3 mm |
| Width (without stand) |
539.8 mm |
| Width (with stand) |
539.8 mm |
| Depth (with stand) |
190 mm |
| Bezel width (side) |
2 mm |
| Bezel width (top) |
2 mm |
| Bezel width (bottom) |
1.05 cm |
| Weight (with stand) |
5.1 kg |
| Weight (without stand) |
3 kg |
| Package width |
734 mm |
| Package depth |
112 mm |
| Package height |
422 mm |
| Package weight |
7.3 kg |
| Packaging data |
|---|
| Package width |
734 mm |
| Package depth |
112 mm |
| Package height |
422 mm |
| Package weight |
7.3 kg |
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
AC, DisplayPort, USB Type-A to USB Type-B |
| DisplayPort cable length |
1.8 m |
| Packaging content |
|---|
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
AC, DisplayPort, USB Type-A to USB Type-B |
| DisplayPort cable length |
1.8 m |
| Other features |
|---|
| Certification |
ENERGY STAR Certified, TCO 10.0, TCO Edge 2.1, EPEAT Gold, RoHS, EU Energy Efficiency Level (Level-C) Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Flicker Free, TÜV Low Blue Light, TÜV Rheinland Eye Comfort (5 Stars) |
| Height (without stand) |
314.8 mm |
| Depth (without stand) |
45.3 mm |
| Width (without stand) |
539.8 mm |
| Power consumption (max) |
66 W |
| Quick start guide |
Yes |
| HDMI |
Yes |
| USB Power Delivery up to |
15 W |
| Energy efficiency scale |
A to G |
| Power supply type |
Internal |
| Power cable length |
1.8 m |
| Touchscreen |
No |
| USB Power Delivery (USB PD) |
Yes |
| Certificates |
|---|
| Certification |
ENERGY STAR Certified, TCO 10.0, TCO Edge 2.1, EPEAT Gold, RoHS, EU Energy Efficiency Level (Level-C) Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Flicker Free, TÜV Low Blue Light, TÜV Rheinland Eye Comfort (5 Stars) |
