Upgrade to elite performance The HP EliteBook 630 is a cost-effective, powerful, and secure PC that allows easy standardization, while giving end-users the tools needed work from almost anywhere. Designed around the fundamental needs of enterprise businesses, this PC features the collaboration, power, and security your business needs to stay on top.
Design | |
---|---|
Product type | Notebook |
Market positioning | Premium |
Form factor | Clamshell |
Product colour | Silver |
Original brand name | HP |
Country of origin | China |
Introduction year | 2022 |
Introduction month | 3 |
Display | |
HD type | Full HD |
Panel type | IPS |
LED backlight | Yes |
Display brightness | 250 cd/m� |
Display diagonal (metric) | 33.8 cm |
Touchscreen | No |
Display resolution | 1920 x 1080 pixels |
Display diagonal | 33.8 cm (13.3") |
Anti-glare screen | Yes |
Display bezel technology | Micro-Edge |
RGB colour space | NTSC |
Colour gamut | 45% |
Native aspect ratio | 16:9 |
Processor | |
Processor generation | 12th gen Intel Core i5 |
Configurable TDP-down | 12 W |
Processor cache type | L3 |
Processor cache | 12 MB |
Processor frequency | 1.3 GHz |
Processor model | i5-1235U |
Processor boost frequency | 4.4 GHz |
Processor cores | 10 |
Processor threads | 12 |
Processor manufacturer | Intel |
Processor family | Intel Core i5 |
Memory | |
ECC | No |
Memory form factor | SO-DIMM |
Internal memory | 8 GB |
Memory layout (slots x size) | 1 x 8 GB |
Internal memory type | DDR4-SDRAM |
Memory clock speed | 3200 MHz |
Memory slots | 2x SO-DIMM |
Maximum internal memory | 64 GB |
Number of free internal memory expansion slots | 1 |
Non-ECC | Yes |
Storage | |
SSD form factor | M.2 |
Storage media | SSD |
Optical drive type | No |
Number of SSDs installed | 1 |
SSD capacity | 256 GB |
SSD interface | PCI Express, NVMe |
Card reader integrated | No |
Total storage capacity | 256 GB |
Total SSDs capacity | 256 GB |
NVMe | Yes |
Graphics | |
Discrete graphics card | No |
On-board graphics card family | Intel Iris Xe Graphics |
On-board graphics card | Yes |
On-board graphics card model | Intel Iris Xe Graphics |
Discrete graphics card model | Not available |
Audio | |
Number of microphones | 2 |
Built-in speaker(s) | Yes |
Number of built-in speakers | 2 |
Built-in microphone | Yes |
Camera | |
Front camera | Yes |
Privacy camera | Yes |
Front camera HD type | HD |
Infrared (IR) camera | Yes |
Optical drive | |
Optical drive type | No |
Network | |
Mobile network connection | No |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
WLAN controller model | Intel Wi-Fi 6E AX211 |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,1000,100 Mbit/s |
Bluetooth | Yes |
Bluetooth version | 5.3 |
Antenna type | 2x2 |
WLAN controller manufacturer | Intel |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB Type-C DisplayPort Alternate Mode | Yes |
HDMI ports quantity | 1 |
HDMI version | 2.0 |
Ethernet LAN (RJ-45) ports | 1 |
Combo headphone/mic port | Yes |
USB Power Delivery | Yes |
Thunderbolt 4 ports quantity | 1 |
Keyboard | |
Pointing device | Clickpad |
Numeric keypad | No |
Spill-resistant keyboard | Yes |
Keyboard special features | Spill-resistant |
Software | |
Pre-installed software | HP Connection Optimizer; HP Hotkey Support; HP MAC Address Manager; HP Support Assistant; HP Power Manager; myHP; HP Privacy Settings; Touchpoint Customizer for Commercial; HP Notifications; HP Quick Touch |
Operating system installed | Windows 11 Pro |
Technical details | |
Market positioning | Premium |
Form factor | Clamshell |
Product colour | Silver |
Number of speakers | 2 |
Sustainable technologies and materials | Low Halogen; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 10% post-consumer recycled plastic; Ocean-bound plastic in speaker enclosure(s) |
Sustainability compliance | Yes |
Sustainability certificates | GS mark, CCC, ENERGY STAR |
Processor special features | |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Trusted Execution Technology | Yes |
Intel Flex Memory Access | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Execute Disable Bit | Yes |
Embedded options available | No |
CPU configuration (max) | 1 |
Intel Virtualization Technology (VT-x) | Yes |
Brand-specific features | |
HP Security tools | Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; HP Sure Click; HP Sure Sense; BIOS Update via Network; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; TPM 2.0 embedded security chip (Common Criteria EAL4+ and FIPS 140-2 Level 2 Certified); HP Sure Start Gen7; HP Wake on WLAN; HP Tamper Lock; HP Sure Run Gen5; HP Sure Recover Gen5; Secured-Core PC Enable |
HP Management tools | HP Client Management Script Library (download); HP Driver Packs (download); HP Client Catalog (download); HP Manageability Integration Kit Gen4 (download); HP Image Assistant Gen5 (download); HP Patch Assistant (download); HP Cloud Recovery; HP Connect for Microsoft Endpoint Manager |
HP speaker type | HP Dual Speakers |
HP Support Assistant | Yes |
HP Smart AC Adapter | Yes |
HP front camera | HP Privacy HD IR |
HP Connection Optimizer | Yes |
HP segment | Business |
HP special features | |
HP Security tools | Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; HP Sure Click; HP Sure Sense; BIOS Update via Network; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; TPM 2.0 embedded security chip (Common Criteria EAL4+ and FIPS 140-2 Level 2 Certified); HP Sure Start Gen7; HP Wake on WLAN; HP Tamper Lock; HP Sure Run Gen5; HP Sure Recover Gen5; Secured-Core PC Enable |
HP Management tools | HP Client Management Script Library (download); HP Driver Packs (download); HP Client Catalog (download); HP Manageability Integration Kit Gen4 (download); HP Image Assistant Gen5 (download); HP Patch Assistant (download); HP Cloud Recovery; HP Connect for Microsoft Endpoint Manager |
HP speaker type | HP Dual Speakers |
HP Support Assistant | Yes |
HP Smart AC Adapter | Yes |
HP front camera | HP Privacy HD IR |
Battery | |
Battery technology | Lithium-Ion (Li-Ion) |
Number of battery cells | 3 |
Battery capacity | 42 Wh |
Battery weight | 180 g |
Power | |
AC adapter power | 45 W |
AC adapter frequency | 50 - 60 Hz |
AC adapter input voltage | 100 - 240 V |
Security | |
Password protection | Yes |
Trusted Platform Module (TPM) | Yes |
Password protection type | BIOS, Power on, User |
Trusted Platform Module (TPM) version | 2.0 |
Certificates | |
Low halogen | Yes |
Sustainability | |
Sustainable technologies and materials | Low Halogen; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 10% post-consumer recycled plastic; Ocean-bound plastic in speaker enclosure(s) |
Sustainability compliance | Yes |
Sustainability certificates | GS mark, CCC, ENERGY STAR |
Weight & dimensions | |
Width | 306.9 mm |
Depth | 208.4 mm |
Height | 15.9 mm |
Weight | 1.28 kg |
Packaging data | |
Package width | 69 mm |
Package height | 305 mm |
Package depth | 449 mm |
Features | |
Country of origin | China |
Supplier features | |
Country of origin | China |
Packaging content | |
Keyboard included | Yes |
Logistics data | |
Harmonized System (HS) code | 8471300000 |
Other features | |
WLAN controller model | Intel Wi-Fi 6E AX211 |
On-board graphics card | Yes |
Number of speakers | 2 |
Display diagonal (metric) | 33.8 cm |
Anti-glare screen | Yes |
Country of origin | China |
Harmonized System (HS) code | 8471300000 |
