WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features two unique blade fans, alternate spinning and 3D active fan, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase air pressure. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
ULTRA DURABLE
ULTRA COOLING
Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
LOW POWER LOSS
Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
LONGER LIFE
Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
| Processor |
| Graphics processor family |
NVIDIA |
| Processor frequency |
1477 MHz |
| Parallel processing technology support |
Not supported |
| Maximum displays per videocard |
4 |
| CUDA cores |
2304 |
| CUDA |
Yes |
| Maximum resolution |
7680 x 4320 pixels |
| Graphics processor |
GeForce RTX 3050 |
| Memory |
| Discrete graphics card memory |
6 GB |
| Memory clock speed |
14000 MHz |
| Memory bus |
96 bit |
| Graphics card memory type |
GDDR6 |
| Ports & interfaces |
| HDMI version |
2.1 |
| HDMI ports quantity |
2 |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
2 |
| Interface type |
PCI Express 4.0 |
| Video |
| DirectX version |
12 Ultimate |
| OpenGL version |
4.6 |
| HDMI version |
2.1 |
| CUDA cores |
2304 |
| Performance |
| NVIDIA G-SYNC |
Yes |
| DirectX version |
12 Ultimate |
| OpenGL version |
4.6 |
| TV tuner integrated |
No |
| Design |
| Number of fans |
2 fan(s) |
| Cooling type |
Active |
| Product colour |
Black, Silver |
| Cooling technology |
GIGABYTE WINDFORCE 2X |
| Software |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Power |
| Minimum system power supply |
300 W |
| Technical details |
| Cooling type |
Active |
| Product colour |
Black, Silver |
| TV tuner integrated |
No |
| System requirements |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Minimum system power supply |
300 W |
| Weight & dimensions |
| Height |
36 mm |
| Depth |
111 mm |
| Length |
191 mm |
| Packaging data |
| Package type |
Box |
| User guide |
Yes |
| Packaging content |
| User guide |
Yes |
