The BT-02B-U3 is currently the smallest and most compact chassis in CHIEFTEC's product portfolio. Despite the mini ITX form factor, the standard components (eg. ODD, Add-On Cards, etc.) can be used for installation to save cost. A 250W SFX Silent PSU is included in the price.
| Design | |
|---|---|
| Side window | No |
| Number of expansion slots | 1 |
| Number of external 5.25" bays | 1 |
| Number of internal 3.5" bays | 1 |
| Number of 2.5" bays | 1 |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 1 |
| Supported motherboard form factors | Mini-ITX |
| Product colour | Black |
| Material | SECC |
| Type | PC |
| Form factor | Mini Tower |
| Power supply | |
|---|---|
| Power supply | 250 W |
| Power supply included | Yes |
| Ports & interfaces | |
|---|---|
| Audio output | Yes |
| Audio input | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Cooling | |
|---|---|
| Rear fans diameters supported | 60 mm |
| Number of rear fans supported (max) | 2 |
| Front fans diameters supported | 80 mm |
| Number of front fans supported (max) | 1 |
| Storage | |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| Weight & dimensions | |
|---|---|
| Material thickness | 0.6 mm |
| Weight | 3.5 kg |
| Height | 295 mm |
| Depth | 240 mm |
| Width | 135 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84733080 |
