850W, DC/DC, 80 PLUS Gold, 120 mm, 2000 RPM, 30.7 dB, 20+4-pin, PCI-e 6+2-pin, 6x SATA, 150 x 160 x 86 mm
PROVEN RELIABILITY, QUIET OPERATION
System Power 10 850W has been built with price-conscious users in mind that do not want to dispense on reliability and quietness. Features such as LLC + SR + DC-to-DC topology and Dual-Rail operation underline the value System Power 10 850W offers even at entry-level.
80 PLUS® GOLD CERTIFICATION
Very high operating efficiency
System Power 10 850W is certified 80 PLUS Gold with an efficiency rating of up to 93.4% – a truly outstanding level for this class of PSUs. The most compelling benefit is lower power consumption, lower costs, and cooler, quieter operation. Whether you are building a very quiet system or gaming system: System Power 10 850W is the price-conscious choice!
EXCEPTIONALLY SILENT OPERATION
Achieved by a silence-optimized 120mm be quiet! fan
The silence-optimized 120mm be quiet! fan is thermally governed to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-class quiet functionality and the almost inaudible operation that be quiet! is famous for.
HIGH-CLASS TECHNOLOGIES
Compatibility for all systems
LLC and Synchronous Rectifier (SR) provide very stable operation and enhanced voltage regulation. The PSU is equipped with DC-to-DC conversion for tight voltage regulation even under heavy cross-loading conditions.
HIGH PERFORMANCE FOR YOUR SYSTEM
Proven reliability for CPU and GPU
System Power 10 850W provides stable and dependable power for CPU and GPU. It is equipped with 2 independent 12V-rails and supports several graphics cards with 4 PCI express connectors for GPU support.
| Power |
|---|
| Power protection features |
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Hold time |
17 ms |
| Efficiency |
93.4% |
| Power Good signal delay range |
100 - 150 ms |
| Max output current (+5Vsb) |
3 A |
| Max output current (-12V) |
0.3 A |
| Max output current (+5V) |
22 A |
| Max output current (+12V2) |
36 A |
| Max output current (+12V1) |
40 A |
| Max output current (+3.3V) |
22 A |
| Combined power (+5Vsb) |
15 W |
| Combined power (-12V) |
3.6 W |
| Combined power (+5V) |
120 W |
| Combined power (+12V) |
849.6 W |
| Combined power (+3.3V) |
120 W |
| Power Factor Correction (PFC) type |
Active |
| Power factor |
0.97 |
| Input current |
5 A |
| AC input frequency |
50 Hz |
| AC input voltage |
200 - 240 V |
| Total power |
850 W |
| Ports & interfaces |
|---|
| Cabling type |
Non-Modular |
| PCI Express connector |
Yes |
| ATX power connector (20+4 pin) |
Yes |
| CPU power cable length |
60 cm |
| CPU power connector (4+4 pin) |
Yes |
| PCI Express power cable length |
65 cm |
| PCI Express power connectors (6+2 pin) |
4 |
| EPS power connector (8-pin) |
Yes |
| Peripheral (Molex) power cable length |
790 mm |
| Peripheral (Molex) power connectors (4-pin) |
1 |
| SATA power cable length |
450,550,570,670,690,790 mm |
| Number of SATA power connectors |
6 |
| Number of PATA power connectors |
1 |
| Motherboard power cable length |
55 cm |
| Motherboard power connector |
20+4 pin ATX |
| Performance |
|---|
| Country of origin |
Germany |
| Certification |
CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia) |
| Mean time between failures (MTBF) |
100000 h |
| Bearing technology |
Rifle |
| Noise level |
30.7 dB |
| EPS version |
2.92 |
| ATX version |
2.52 |
| 80 PLUS certification |
80 PLUS Gold |
| Power supply unit (PSU) form factor |
ATX |
| Purpose |
PC |
| Design |
|---|
| On/off switch |
Yes |
| Fan speed |
0 - 2000 RPM |
| Number of fans |
1 fan(s) |
| Fan diameter |
12 cm |
| Cooling type |
Active |
| Product colour |
Black |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
2.14 kg |
| Height |
150 mm |
| Depth |
86 mm |
| Width |
160 mm |
| Packaging data |
|---|
| Package weight |
2.6 kg |
| Package height |
100 mm |
| Package depth |
300 mm |
| Package width |
220 mm |
| Manual languages |
German, English, Spanish, French, Polish, Russian |
| Manual |
Yes |
| Technical details |
|---|
| Sustainability certificates |
CCC, CE, ENERGY STAR, ErP, Federal Communications Commission (FCC), RoHS, WEEE |
| Warranty period |
5 year(s) |
| Other features |
|---|
| Noise level (full-load mode, 100%) |
30.7 dB |
| Noise level (quiet mode, 50%) |
10.4 dB |
| Noise level (silent mode, |
10.3 dB |
| Screws included |
Yes |
