ASUS Pro business motherboards provide enhanced features to smooth your IT operations, including comprehensive system protection, 24/7 stability and reliability and an improved management suite for easier customization. Known as the world's biggest and best-known motherboard brand, ASUS provides world-class after-sales service and guaranteed long-term availability to maximize your investment over the product life cycle and offers a high-quality, TCO-optimized solution for your business computing-needs.
ASUS Corporate Stable Model
ASUS Corporate Stable Model (CSM) is a commercial program designed to provide stable and reliable motherboards. Offering up to 36-month product lifecycle support and 6-month end-of-life notice to allow sufficient lead times for your organization to get ready for product transitions. Each purchase of an ASUS CSM motherboard comes with ASUS Control Center Express - server-grade IT management software.
| Internal I/O |
| Number of M.2 (M) slots |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Audio connector |
Yes |
| Supported storage drive interfaces |
M.2, SATA III |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| Number of SATA III connectors |
6 |
| Number of COM connectors |
2 |
| Number of chassis fan connectors |
2 |
| Front panel audio connector |
Yes |
| EPS power connector (8-pin) |
Yes |
| CPU fan connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| Technical details |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel Q670 |
| Supported processor sockets |
LGA 1700 |
| Parallel processing technology support |
Not supported |
| HDMI version |
2.1 |
| Cooling type |
Active |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Number of mounting holes |
8 |
| Audio |
| Audio output channels |
7.1 channels |
| Performance |
| Number of HDDs supported |
6 |
| Supported storage drive types |
HDD & SSD |
| Windows operating systems supported |
Windows 10 x64, Windows 11 |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel Q670 |
| RAID levels |
0, 1, 5, 10 |
| Supported processor sockets |
LGA 1700 |
| Cooling type |
Active |
| Audio output channels |
7.1 channels |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Expansion card interfaces |
| Audio connector |
Yes |
| Processor |
| Processor manufacturer |
Intel |
| Compatible processor series |
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel Pentium G |
| Supported processor sockets |
LGA 1700 |
| Processor socket |
LGA 1700 |
| Memory |
| Number of memory slots |
4 |
| Memory slots type |
DIMM |
| Supported memory types |
DDR5-SDRAM |
| Memory channels |
Dual-channel |
| Supported memory clock speeds |
4800,5000,5200,5400,5600 MHz |
| Maximum internal memory |
192 GB |
| ECC сompatibility |
Non-ECC |
| Storage controllers |
| Number of HDDs supported |
6 |
| Supported storage drive types |
HDD & SSD |
| Supported storage drive interfaces |
M.2, SATA III |
| RAID levels |
0, 1, 5, 10 |
| Number of storage drives supported |
8 |
| RAID support |
Yes |
| Graphics |
| Parallel processing technology support |
Not supported |
| Rear panel I/O ports |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| DisplayPort version |
1.4 |
| USB 2.0 ports quantity |
2 |
| VGA (D-Sub) ports quantity |
0 |
| PS/2 ports quantity |
2 |
| Microphone in |
Yes |
| Headphone outputs |
2 |
| HDMI version |
2.1 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| DVI-D ports quantity |
0 |
| DisplayPorts quantity |
1 |
| Network |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet interface type |
Gigabit Ethernet |
| Features |
| Power source type |
ATX |
| Number of mounting holes |
8 |
| Windows operating systems supported |
Windows 10 x64, Windows 11 |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel Q670 |
| Supported processor sockets |
LGA 1700 |
| Cooling type |
Active |
| Audio output channels |
7.1 channels |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Expansion slots |
| Number of M.2 (M) slots |
2 |
| PCI Express x1 (Gen 3.x) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| BIOS |
| BIOS memory size |
256 Mbit |
| Power |
| Power source type |
ATX |
| Software |
| Windows operating systems supported |
Windows 10 x64, Windows 11 |
| Drivers included |
Yes |
| Weight & dimensions |
| Width |
244 mm |
| Depth |
244 mm |
| Packaging content |
| Drivers included |
Yes |
| Cables included |
SATA |
