POLYCHROME RGB
This motherboard features onboard RGB headers and addressable RGB headers that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects
High Speed M.2 Solution(PCIe Gen4 x4)
Supports PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.
Dual HDMI Outputs
Equipped with two of the most widely used HDMI connectors, enjoy better multi-monitor compatibility and an easy setup experience.
Dragon 2.5 Gb/s LAN
The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you’ll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.
M.2 (KEY E) For WiFi
Besides the onboard LAN port, users may also choose wireless connections by M.2 (Key E) slot.
HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.
| Internal I/O |
| Number of M.2 (M) slots |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Total number of SATA connectors |
4 |
| Front panel connector |
Yes |
| Supported storage drive interfaces |
M.2, SATA III |
| USB 2.0 connectors |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| TPM connector |
Yes |
| Number of SATA III connectors |
4 |
| EPS power connector (8-pin) |
Yes |
| CPU fan connector |
Yes |
| Chassis intrusion connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| Technical details |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B760 |
| Supported processor sockets |
LGA 1700 |
| Parallel processing technology support |
Not supported |
| HDMI version |
2.1 |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Total number of SATA connectors |
4 |
| Maximum internal memory supported by processor |
128 GB |
| Audio |
| Audio output channels |
7.1 channels |
| Performance |
| Number of HDDs supported |
6 |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B760 |
| RAID levels |
0, 1, 5, 10 |
| Supported processor sockets |
LGA 1700 |
| Certification |
- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) |
| Audio output channels |
7.1 channels |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Processor |
| Processor manufacturer |
Intel |
| Maximum internal memory supported by processor |
128 GB |
| Compatible processor series |
Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Supported processor sockets |
LGA 1700 |
| Maximum number of SMP processors |
1 |
| Processor socket |
LGA 1700 |
| Memory |
| Number of memory slots |
2 |
| Memory slots type |
DIMM |
| Supported memory types |
DDR5-SDRAM |
| Memory channels |
Dual-channel |
| Supported memory clock speeds |
5600,6800,7200 MHz |
| Maximum internal memory |
128 GB |
| Unbuffered memory |
Yes |
| Supported memory clock speed (max) |
7200 MHz |
| ECC сompatibility |
Non-ECC |
| Storage controllers |
| Number of HDDs supported |
6 |
| Supported storage drive interfaces |
M.2, SATA III |
| RAID levels |
0, 1, 5, 10 |
| Number of storage drives supported |
4 |
| RAID support |
Yes |
| Graphics |
| Parallel processing technology support |
Not supported |
| HDCP |
Yes |
| Rear panel I/O ports |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| USB 2.0 ports quantity |
2 |
| VGA (D-Sub) ports quantity |
0 |
| PS/2 ports quantity |
1 |
| Microphone in |
Yes |
| HDMI version |
2.1 |
| HDMI ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| DVI-D ports quantity |
0 |
| Line-in |
Yes |
| Network |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Features |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B760 |
| Supported processor sockets |
LGA 1700 |
| Certification |
- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) |
| Audio output channels |
7.1 channels |
| Motherboard form factor |
micro ATX |
| Component for |
PC |
| Audio chip |
Realtek ALC897 |
| Expansion slots |
| Number of M.2 (M) slots |
2 |
| PCI Express x1 (Gen 3.x) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| BIOS |
| BIOS type |
UEFI AMI |
| BIOS memory size |
128 Mbit |
| Video |
| HDCP |
Yes |
| Certificates |
| Certification |
- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) |
| Software |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Weight & dimensions |
| Width |
244 mm |
| Depth |
201 mm |
| Packaging content |
| Cables included |
SATA |
